SY-HP200
SY-HP200 Mini Mobile Cone Crusher
Compact cone crushing solution
The SY-HP200 Mobile Cone Crusher is a crawler-mounted plant engineered for secondary hard rock processing. Delivering 180-280 TPH with a 190mm max feed, it features hydraulic overload protection and single or dual power options. Ideal for remote quarries and recycling, its self-contained design ensures rapid site deployment and eliminates complex infrastructure needs.
Product Parameters
| Project | Name | SY-JHP200 |
|---|---|---|
| Feeding section | Feeding capacity (t/h) | 200 |
| Hopper volume (m³) | 3 | |
| Feeding belt | Length × Width (mm) | 4550×1350 |
| Feeding height (mm) | 2700 | |
| Power (kW) | 5.5×2 | |
| Crusher | cone crusher | HP200 |
| Maximum feed particle size (mm) | 190 | |
| Adjustment range of discharge opening (mm) | 8-44 | |
| Crusher weight (t) | 12 | |
| Crusher power (kW) | 160 | |
| main belt | Length × Width (mm) | 11000×1600 |
| Discharge height (mm) | 3500 | |
| Power (kW) | 9.2×2 | |
| Finished belt (undersize belt) | Length × Width (mm) | 5200×1350 |
| Discharge height (mm) | 2650 | |
| Power (kW) | 5.5×2 | |
| Return material hanging screen | Hanging screen size (mm) | 4800×2160 |
| Power (kW) | 3.7*2 | |
| Screen mesh size (mm) | 4200×1540 | |
| Transitional belt A | Length × Width (mm) | 2100×970 |
| Power (kW) | 3 | |
| Return belt | Length × Width (mm) | 8930×770 |
| Power (kW) | 5.5 | |
| complete machine | Overall weight (t) | 37.3 |
| Machine processing capacity (t/h) | 180-280 | |
| Total work done in crushing (kW) | 223 | |
| Working dimensions (length, width, height/mm) | 16700×3800×4100 | |
| Transportation dimensions (length, width, height/mm) | 17600×3800×3450 |
Applicable Materials
Power Options
Emission Standards
Service & Support
- 12-Month Warranty
- Installation & Training
- Remote Diagnostics
- Spare Parts Supply
Application
The SY‑HP200 is ideal for secondary or tertiary crushing in small- to medium-scale operations. Typical applications include:
- On-site Processing: Ideal for the on-site processing of granite, basalt, and ore for construction aggregates.
- Mobile Adaptability: Suited for situations requiring mobile adaptability, such as road maintenance, remote-site quarrying, and waste recycling, where rapid relocation and minimal setup are essential.
- Space-Constrained Environments: Perfect for project environments with space constraints or short timelines, benefiting from its compact, self-contained crawler design that eliminates the need for extensive infrastructure.
With a throughput range of 100–250 tonnes per hour, SY‑HP200 Mini Mobile Cone Crusher strikes a balance between portability and productivity, making it well-suited to projects needing efficient secondary/tertiary crushing without the burden of large stationary plants.
Working Principle
SS‑7018 Mobile Inclined Vibrating Screening Plant is equipped with an inclined, multi-deck vibrating screen powered by vibration motors or eccentric blocks. Materials are fed into the unit’s hopper and distributed evenly onto the screen decks. As the decks vibrate, material stratifies naturally by size and is separated through appropriately sized mesh layers. Oversized particles remain on top, while finer ones pass through successive decks.
The angle and eccentric rotation create a powerful multi-point pressure that gradually reduces the material to the desired size. Hydraulic systems adjust the discharge gap and provide overload protection: if uncrushable material enters, the crusher automatically opens slightly to allow it to pass before resetting—a design that ensures safety and reduces downtime. The entire unit—crusher, hydraulic systems, and conveyors—is integrated, enabling fast deployment and reliable performance.
Request A Quote
Tell us your raw material, required capacity, feeding size and final output size. Our engineer will recommend the suitable model for your project.
